Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process

Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process

customized automatic winding machine

magnet wire coiling machine

metal metallurgy winding machine

مكان المنشأ:

الصين

اسم العلامة التجارية:

YUYANG

إصدار الشهادات:

CE

رقم الموديل:

YYH-20AB

اتصل بنا
اطلب اقتباس
تفاصيل المنتج
ماكس متقلبة القوة:
20 كيلو وات
قوة العمل:
340 فولت-430 فولت
الحد الأقصى لتيار الإدخال:
30 أ
طاقة الإخراج:
20 كيلو وات
تردد متقلب:
50-250 كيلو هرتز
معدل تدفق مياه التبريد:
0.2 ميجا باسكال، 6 لتر/دقيقة
نقطة حماية درجة حرارة الماء:
40 ج
حجم المنتج:
560x260x560 ملم
الوزن الصافي:
28 كجم
إبراز:

customized automatic winding machine

,

magnet wire coiling machine

,

metal metallurgy winding machine

شروط الدفع والشحن
الحد الأدنى لكمية
1 مجموعة
الأسعار
$2000
تفاصيل التغليف
صندوق من الخشب الرقائقي
وقت التسليم
5-10 أيام عمل
شروط الدفع
/ تي تي، خطاب الاعتماد، ويسترن يونيون
القدرة على العرض
200 مجموعات شهريا
وصف المنتج
Customized Automatic Magnet Wire Winding Machine
This advanced induction heating machine is specifically designed for metal and metallurgy coiling processes, offering efficient, secure, and environmentally friendly operation.
Key Characteristics
  • IGBT inverting device with automatic frequency tracking
  • High-frequency operation with rapid heating and 20-30% lower power consumption compared to electronic tube induction heating
  • Secure voltage operation with enhanced safety features
  • Manual and automatic regulation with comprehensive protection against over voltage, over current, water shortage, phase failure, and overheating
  • No open-fire, noise, or pollution - environmentally friendly and fire-safe
  • Recommended for brazing, welding, forging, hot cooperation, melting, quenching, and annealing processes
Advanced Features
Utilizing the most advanced electric components and unique high-new techniques, this high-frequency induction heating machine provides rapid, localized metal heating. It can penetrate non-metal materials to heat metals until fusion without direct contact, solving technical problems safely and efficiently without pollution.
Technical Advantages
  • Portable design: 80% space savings and 75% weight reduction compared to traditional transformers
  • Monolithic shell design with resistance to weak acids and alkalis
  • Advanced amorphous magnetic core material for complex metallic heating
  • Wider frequency range for irregular shaped workpieces
  • Efficient heating with 8-second speed for air conditioning and refrigerator industry applications
  • Stable magnetic field output for consistent long-term heating performance
Technical Parameters
Model YYH-20AB (Three phase)
Work Power 340v-430v
Maximum Input Current 30A
Output Power 20kw
Fluctuating Frequency 50-250KHZ
Cooling Water Flow Rate 0.2Mpa, 6L/min
Water Temperature Protection Point 40°C
Product Size (Main Unit) 560x260x560mm
Product Size (Transformer) 390x260x370mm
Net Weight (Main Unit) 28kg
Net Weight (Transformer) 16kg
Application Areas
  • Brazing materials: copper, brass, tungsten steel, stainless steel, iron, aluminum, and other metal brazing
  • Glasses welding, fishing tool welding, hardware appliances welding
  • Carbide saw and saw-tooth welding, carbide blade welding
  • Jewelry and watches welding
  • Electronic industry: motor rotor hot-cooperate, electrode silver soldering and tin soldering
  • Metal implants, bulbs fight electrode
  • Band accessory soldering, golf head, pipe welding
  • Communication equipment soldering, copper coaxial cable connector soldering
Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process 0 Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process 1
